Electric Scaffolding

Scaffolding Lift

Platform Height

2-12m

Max. Lifting Capacity

300kg/500kg

Motor Size

PA800/ PA1000

Request a Quote Brochure

Electric Scaffolding

Features

Parameters

Request a Quote

Brochure

Features

+ Expand All - Collapse All

Efficient Electric Lifting System

+ -

Adjustable Working Height

+ -

Height can be easily adjusted to meet various construction or maintenance needs, ensuring flexibility and safety.

Compact & Easy to Move

+ -

Lightweight design with lockable wheels allows easy movement and quick setup, even in narrow spaces.

Strong & Safe Structure

+ -

Built with high-strength steel frame, guardrails, and safety lock system to ensure stability during operation.

Parameters

Brochure

Platform Height

2-12m

Max. Lifting Capacity

300kg/500kg

Motor Size

PA800/ PA1000

Platform Size

1.3*0.68m/1.4*0.78m/1.58*0.98m/1.78*1.2m

Dimension

1.5*0.7m/1.6*0.8m/1.8*1m/2*1.3m

Material

5*5cm steel pipe, 2mm thickness

Platform Material

Steel plate

Wire Rope Diameter

6mm

Castor Diameter

6 inches, two directional wheels, two universal wheels, with brakes

Limiter

Upper and lower limiter

Packing

Wooden case (especially for export)

FAQ

+ Expand All - Collapse All

What is an electric scaffold used for?

+ -

Electric scaffolds are used for façade work, installation, maintenance, and construction at height.

What is the load capacity of an electric scaffold?

+ -

Standard load capacity ranges from 300kg to 800kg, depending on the model.

Is the electric scaffold safe to operate?

+ -

Yes. It is equipped with safety locks, emergency stop, and overload protection.
